Axis 01995-001 video intercom system 5 MP Black
- Anti-ligature, vandal-resistant IK10-rated; Easy installation with PoE; High-quality audio and video; IP66/IP69-rated with wall-mount; Open interface with IP phone integration, SIP support
AXIS I8016-LVE Network Video Intercom is a compact and highly robust network intercom designed for two-way communication, video identification, and remote entry control. It offers 5 MP resolution with invisible IR night vision, and exceptional audio volume with echo and noise cancellation to ensure reliable 24/7 identification even in the most demanding situations. Based on open IP standards and interfaces, this network intercom offers great integration possibilities and is a perfect complement to any video surveillance system. Furthermore, it features multiple inputs and outputs for remote control of door locks and other equipment.
| Technical details | |
|---|---|
| Door station control | Yes |
| VoIP protocols | secondary SIP server, IPv6, SRTP, SIPS, SIP TLS, DTMF (RFC2976 and RFC2833), NAT (ICE, STUN, TURN), Contact list, parallel call forking, sequential call forking |
| Echo cancellation | Yes |
| Automatic gain control | Yes |
| Motion detection function | Yes |
| Relay inputs | 1 |
| Streaming capability | Yes |
| Wall mountable | Yes |
| Built-in microphone | Yes |
| Contrast adjustment | Yes |
| Maximum indoor range | 5 m |
| Maximum number of cameras supported | 1 |
| Speakerphone | Yes |
| Colour | Yes |
| Connectivity technology | Wired |
| Camera | |
|---|---|
| PTZ control | Yes |
| Maximum frame rate | 30 fps |
| Viewing angle, horizontal | 140° |
| Viewing angle, vertical | 114° |
| Sensor type | CMOS |
| Maximum video resolution | 2592 x 1944 pixels |
| Megapixel (approx.) | 5 MP |
| Night vision | |
|---|---|
| LED type | IR |
| Night vision | Yes |
| Audio | |
|---|---|
| Voice codecs | G.722, G.726-32, OPUS, PCM, PCMA |
| Noise-canceling | Yes |
| Number of speakers | 1 |
| Built-in speaker(s) | Yes |
| Design | |
|---|---|
| Housing material | Plastic, Stainless steel, Zinc |
| Control type | Wireless |
| Proper use | Outdoor |
| IK code | IK10 |
| Number of OSD languages | 12 |
| Vandal-proof | Yes |
| International Protection (IP) code | IP66, IP69 |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Product colour | Black |
| Network | |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPSa , HTTP/2, SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, NTCIP, SIP, LLDP, Syslog |
| Power over Ethernet (PoE) | Yes |
| Management features | |
|---|---|
| Syslog | Yes |
| Power | |
|---|---|
| Power consumption (typical) | 4.7 W |
| Operating current (door opener) | 0.7 A |
| Operating voltage (door opener) | 30 V |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -40 – 60 °C |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating relative humidity (H-H) | 10 – 100% |
| Weight & dimensions | |
|---|---|
| Weight | 900 g |
| Height | 124 mm |
| Width | 124 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176920 |
