Axis 02542-001 network video recorder 2U Silver
- 96 AXIS Camera Station licenses included; Available in 2 variants: 96 TB and 192 TB; Extensive support and 5-year warranty; Flexible storage options including RAID; Scalable and powerful solution
Featuring powerful components, this secure, scalable recording server offers high performance and support for powerful applications and features. It includes AXIS Camera Station licenses and multiple RAID configurations for flexible storage and multiple redundancy configuration. And, a Trusted Platform Module (FIPS 140-2 level 2 certified) ensures secure storage of all cryptographic keys and certificates. Available in two variants with a choice of storage, it comes preloaded with preconfigured software. Plus, all supported products are available in one price list for a one-stop-shop experience. Furthermore, it offers services such as Keep Your Hard Drive, Next Business Day Onsite Support, and a 5-year warranty.
| Performance | |
|---|---|
| Maximum frame rate | 30 fps |
| Operating system installed | Windows 10 IoT Enterprise |
| Internal memory | 32768 MB |
| Video input channels | 150 channels |
| Wireless LAN features | |
|---|---|
| Wi-Fi | No |
| Hard drive | |
|---|---|
| RAID levels | 0, 1, 5, 6, 10 |
| RAID support | Yes |
| Maximum storage capacity | 96 TB |
| HDD capacity | 8 TB |
| Number of HDDs installed | 12 |
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| VGA (D-Sub) output ports | 2 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN data rates | 1000,10000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 4 |
| Features | |
|---|---|
| Certification | EN 55032 Class A, EN 55024, EN 55035, EN 61000-3-2, EN 61000-3-3, FCC Part 2 and 15 Class A, ISED ICES-003 Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835, VCCI 32-1 Class A, BSMI |
| Product colour | Silver |
| Rack capacity | 2U |
| Rack mounting | Yes |
| Processor | |
|---|---|
| Built-in processor | Yes |
| Power | |
|---|---|
| Power supply | 1600 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 – 240 V |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -40 – 65 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| Operating temperature (T-T) | 10 – 35 °C |
| Weight & dimensions | |
|---|---|
| Weight | 22.9 kg |
| Height | 87 mm |
| Depth | 721.6 mm |
| Width | 482 mm |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
- manual pdf
- manual pdf
- leaflet
