Axis 02668-001 security camera Box IP security camera Indoor 768 x 576 pixels Wall
- Thermometric guard tour capabilities
- Early fire detection analytics
- Spot temperature reading
- Built-in cybersecurity features
- Support for edge-to-edge technology
Ideal for patrolling large sites, this robust thermal camera lets you remotely monitor temperatures and trigger temperature-based events. It offers early fire detection analytics and built-in cybersecurity features.
What’s the temperature?
AXIS Q2101-TE lets you remotely monitor temperatures over large areas—automatically or manually with just one camera. It can monitor temperatures from -40 °C to 350 °C (-40 °F to 660 °F) with several trigger types such as lowest and highest temperature or temperature gradient. When mounted on a positioning unit (sold separately), this robust camera provides a 360° unobstructed field of view. This also enables thermometric guard tour with support for up to 256 presets with 10 polygonal detection areas each. Spot temperature reading acts as a visual aid and lets you see the exact temperature in a specific area. Additionally, temperature metadata enables statistics, follow up, and process analysis.
Detect early signs of fire
Built on ARTPEC 8, the latest Axis system-on-chip (SoC), AXIS Q2101-TE offers powerful analytics capabilities. It comes with early fire detection analytics preinstalled making it possible to set triggers and get warnings about early signs of fire or potential overheating. Using smart filtering, the analytics can disregard uninteresting hot objects such as the warm exhausts of passing work vehicles for reduced false alarms.
Depend on it – robust and secure
This reliable, IK10-, NEMA 4X-rated thermal camera is ideal for monitoring critical assets. It includes built-in cybersecurity features to help prevent unauthorized access and safeguard your system. For instance, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis products on your network. It also includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified. Thanks to electronic image stabilization (EIS), this robust camera provides smooth video even in scenes with vibrations. And, with four I/O ports and support for edge-to-edge technology it’s possible to connect a network speaker to enable audio alarms.
| Performance | |
|---|---|
| Certification | CSA, UL/cUL, UKCA, CE, KC, VCCI, RCM |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Thermal sensitivity (NETD) | 40 mK |
| Number of languages | 12 |
| Processor model | ARTPEC-8 |
| Built-in processor | Yes |
| Thermal module | Yes |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Type | IP security camera |
| Design | |
|---|---|
| IK code | IK10 |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium |
| Product colour | White |
| Mounting type | Wall |
| Form factor | Box |
| Camera | |
|---|---|
| Camera pixel size | 17 µm |
| Field of view (FOV) angle | 19.4° |
| Camera tilt control | Yes |
| Camera pan control | Yes |
| Image sensor | |
|---|---|
| Sensor type (thermal module) | Noise equivalent temperature difference (NETD) |
| Sensor type | Microbolometer |
| Lens system | |
|---|---|
| Maximum aperture number | 1.23 |
| Lens diameter | 1.9 cm |
| Night vision | |
|---|---|
| Night vision | No |
| Video | |
|---|---|
| Privacy masking | Yes |
| Gain control type | Auto |
| Video streaming | Yes |
| Frame rate | 8.3 fps |
| Video recording | Yes |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 768 x 576 pixels |
| Audio | |
|---|---|
| Audio system full duplex | Yes |
| Audio system | 2-way |
| Network | |
|---|---|
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Ethernet interface type | Gigabit Ethernet |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| Internal memory | 2048 MB |
| Flash memory | 8192 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Terminal block port | Yes |
| Headphone outputs | 2 |
| RS-485 ports | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
|---|---|
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| IP address filtering | Yes |
| Mirror | Yes |
| Digest authentication | Yes |
| Network access storage (NAS) | Yes |
| Pixel counter | Yes |
| Password protection | Yes |
| Fire detection | Yes |
| Temperature measurement accuracy | 5 °C |
| Temperature measurement range | -40 – 350 °C |
| Temperature sensor | Yes |
| Power | |
|---|---|
| DC output voltage | 8, 9, 10, 12, 15, 16, 24, 28 |
| Power consumption (Power over Ethernet (PoE)) | 4.6 W |
| Power consumption (max) | 25.5 W |
| Power consumption (typical) | 4.1 W |
| Power source type | DC, PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Operating relative humidity (H-H) | 10 – 100% |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating temperature (T-T) | -40 – 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 3.3 kg |
| Height | 159 mm |
| Depth | 404 mm |
| Width | 150 mm |
| Packaging content | |
|---|---|
| Packaging content | TORX T30 bit, TORX T20 screwdriver, terminal block connectors, connector guard, cable gaskets, owner authentication key |
| Manual | Yes |
| Number of cameras | 1 |
