Datamax O’Neil PC42t label printer Thermal transfer 203 x 203 DPI 101.6 mm/sec Wired Ethernet LAN
- Thermal transfer
- 203 x 203 DPI
- Maximum printing width: 10.4 cm Print speed: 101.6 mm/sec
- Built-in barcodes: 1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, POSTNET, QR Code
- Connectivity technology: Wired
- USB port Ethernet LAN
- Display: LED
- 2.5 kg
Easy to install and ready to print quickly, the streamlined PC42t thermal transfer desktop printer is an economical choice for media up to 110 mm (4.3 in) wide. Able to accommodate large ribbon sizes, the PC42t printer can print longer before needing media replenishment, thus improving the productivity of labeling workflows.
The PC42t Desktop Printer sets a new standard for user-friendliness and affordability. Exceptionally compact and easy to use, this printer is simple to install and ready to print quickly. Quiet, reliable operation and intuitive design make the PC42t the right fit for light-duty labeling applications in a variety of industries.
Available in either 12.7 mm (0.5 in) or 25.4 mm (1 in) ribbon core configurations, the PC42t printer supports media as wide as 110 mm (4.3 in) and fits right into existing printing environments. The 25.4 mm configuration is compatible with ribbon lengths up to 300 m (984 ft) – more than four times the length of competitive offerings. This reduces downtime and means ribbons can be shared with larger printers.
PC42t printers include industry-standard connectivity, with up to four ports: standard USB device and host, plus optional serial or serial+Ethernet. With a user-installable USB-to-parallel cable, PC42t printers easily drop into virtually any environment.
Compact size, support for common media as well as ZPL-II and EPL emulation and Honeywell Direct Protocol (DP), mean that PC42t printers are an easy upgrade from a variety of legacy Intermec and competitive printers.
The PC42t printer is priced affordably, includes modern features, and is a smart solution for small or medium businesses looking to improve productivity in labeling applications.
Printing | |
---|---|
Maximum printing width | 10.4 cm |
Print speed | 101.6 mm/sec |
Maximum resolution | 203 x 203 DPI |
Colour | No |
Print technology | Thermal transfer |
Paper handling | |
---|---|
Maximum media length | 9.6 mm |
Supported paper width | 25.4 – 110 mm |
Maximum label width | 11 cm |
Maximum roll diameter | 12.7 cm |
Core diameter | 1.27 cm |
Ribbon length | 75 m |
Ribbon width | 10.9 cm |
Ports & interfaces | |
---|---|
Optional connectivity | Ethernet, Serial (RS-232) |
USB 2.0 ports quantity | 1 |
USB port | Yes |
Bluetooth | No |
Wi-Fi | No |
Ethernet LAN | Yes |
Connectivity technology | Wired |
Performance | |
---|---|
Certification | UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM |
Built-in barcodes | 1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, POSTNET, QR Code |
Flash memory | 64 MB |
Internal memory | 64 MB |
Design | |
---|---|
Housing material | Metal, Plastic |
Display | LED |
Built-in display | Yes |
Product colour | Black |
Power | |
---|---|
AC adapter output current | 2.5 A |
AC adapter output voltage | 24 V |
AC input frequency | 50 – 60 Hz |
AC input voltage | 100 – 240 V |
System requirements | |
---|---|
Windows operating systems supported | Windows NT, Windows Vista, Windows XP |
Operational conditions | |
---|---|
Operating temperature (T-T) | 5 – 40 °C |
Storage temperature (T-T) | -40 – 60 °C |
Storage relative humidity (H-H) | 10 – 90% |
Operating relative humidity (H-H) | 10 – 80% |
Weight & dimensions | |
---|---|
Weight | 2.5 kg |
Height | 177 mm |
Depth | 297 mm |
Width | 226 mm |
Packaging data | |
---|---|
Package type | Box |
Quantity per pack | 1 pc(s) |
Logistics data | |
---|---|
Harmonized System (HS) code | 84433210 |
Other features | |
---|---|
Plug and Play | Yes |
Languages support | Multi |
LED indicators | Yes |
