Mellanox Technologies MSN2010-CB2FC network switch Managed 1U Black
- Managed Web-based management
- Configuring Location Settings (CLI)
- Fiber
- Switching capacity: 1700 Gbit/s
- 1U Rack mounting
The SN2010 switch is the ideal top of rack (ToR) solution for hyperconverged and storage deployments. Packed with 18 ports of 10/25GbE and 4 splittable ports of 40/100GbE, the SN2010 can deliver up to 1.7Tb/s aggregate throughput.
All SpectrumTM-based switches including the SN2010 support low-latency line rate traffic for all packet sizes and are ONIE bootable with support for Cumulus Linux, Mellanox Onyx (previously MLNX-OS for Ethernet), and other open source operating systems with a broad installed base that drives the world’s most innovative data center infrastructures. SN2010 introduces low latency for 10/25GbE and 100GbE switching, features a robust implementation of data, control and management planes, and offers the most compact form factor and lowest power consumption.
SN2010 supports the same features and scale as SN2700. The SN2010 design allows either stand-alone single switch installation, or side-by-side placement of two switches in a single 1RU slot of a 19″ rack, delivering high availability to the hosts.
| Management features |
| Configuring Location Settings (CLI) |
Yes |
| Web-based management |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
| Power connector |
AC-in jack |
| SFP28 ports quantity |
18 |
| QSFP28 ports quantity |
4 |
| Fiber optic connector |
QSFP28, SFP28 |
| Basic switching RJ-45 Ethernet ports type |
No |
| Network |
| Link aggregation |
Yes |
| Flow control support |
Yes |
| Broadcast storm control |
Yes |
| Port mirroring |
Yes |
| Zero Touch Provisioning (ZTP) |
Yes |
| Cable types supported |
Fiber |
| Optical fiber |
| Switching optical modules type |
100 Gigabit Ethernet |
| Data transmission |
| Jumbo frames |
9216 |
| Jumbo frames support |
Yes |
| Store-and-forward |
Yes |
| Switching capacity |
1700 Gbit/s |
| Security |
| Loop protection |
Yes |
| BPDU filtering/protection |
Yes |
| Root protection |
Yes |
| Design |
| Product colour |
Black |
| Form factor |
1U |
| Rack mounting |
Yes |
| Performance |
| sFlow |
Yes |
| Built-in processor |
Yes |
| Power |
| Power consumption (typical) |
57 W |
| AC input voltage |
100 – 240 V |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Weight & dimensions |
| Weight |
4.54 kg |
| Height |
43.8 mm |
| Depth |
508 mm |
| Width |
200 mm |
| Certificates |
| Certification |
RoHS |
