StarTech.com Gigabit Ethernet Fiber Media Converter with Open SFP Slot
- Wired
- 1250 Mbit/s
- Ethernet LAN (RJ-45) ports: 1
- Fiber ports quantity: 1 SFP
- Black
Convert and extend a Gigabit Ethernet connection over fiber using the Gigabit SFP of your choice
The ET91000SFP2 Open SFP Fiber Media Converter converts and extends a Gigabit Ethernet connection over fiber, using the Gigabit SFP of your choice.
A versatile solution for connecting an Ethernet (1000Base-T) network to remote network segments over a fiber backbone, the media converter features an open SFP slot that lets you choose the MSA-Compliant Gigabit SFP that best suits your fiber connection mode (single / multi-mode) and distance requirements (see our full line of for compatible solutions).
The fiber to Ethernet converter has a durable all-steel chassis and offers simple plug-and-play installation, while support for full-duplex operation and Jumbo Frame support provides efficient network operation.
For added versatility, this Gigabit media converter supports standalone operation, or installation into the 20 Slot, ETCHS2U” text=”2U Rackmount Chassis (ETCHS2U). For applications where multiple chassis-mounted media converters are required, this Gigabit media converter can be purchased as a ET91000SFP2C” text=”Card Module only (ET91000SFP2C).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
– Install the SFP of your choice with the open SFP slot
– Operate as a standalone media converter or install into the ETCHS2U chassis
– Ensure maximum up-time with link-loss forwarding and remote status monitoring
Network | |
---|---|
Duplex system | Full, Half |
Auto MDI/MDI-X | Yes |
Ethernet LAN data rates | 1000 Mbit/s |
Ethernet interface type | Gigabit Ethernet |
Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z |
Converter output interface | 1000Base-LX, 1000Base-SX |
Converter input interface | 1000Base-T |
Maximum data transfer rate | 1250 Mbit/s |
Performance | |
---|---|
Mean time between failures (MTBF) | 65000 h |
Features | |
---|---|
Housing material | Steel |
LED indicators | Yes |
Product colour | Black |
Internal | No |
Ports & interfaces | |
---|---|
Fiber optic connector | SFP |
Fiber ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wired |
Power | |
---|---|
External power adapter | Yes |
Power over Ethernet (PoE) | No |
Power consumption (typical) | 8 W |
Output current | 1 A |
Output voltage | 12 V |
Input current | 0.36 A |
Input voltage | 100 – 240 V |
Weight & dimensions | |
---|---|
Weight | 400 g |
Height | 20 mm |
Depth | 160 mm |
Width | 95 mm |
Operational conditions | |
---|---|
Operating relative humidity (H-H) | 10 – 90% |
Storage temperature (T-T) | -10 – 70 °C |
Operating temperature (T-T) | 0 – 60 °C |
Packaging content | |
---|---|
Manual | Yes |
Packaging data | |
---|---|
Package weight | 786 g |
Package height | 92 mm |
Package depth | 208 mm |
Package width | 137 mm |
Certificates | |
---|---|
Certification | FCC |
Compliance certificates | RoHS |
Logistics data | |
---|---|
Harmonized System (HS) code | 85176990 |
