TieDex UK Allied Telesis AT MC101XL – fibre media converter – 10Mb LAN
Allied Telesis AT MC101XL – Fibre media converter – 10Mb LAN – 100Base-FX, 100Base-TX – RJ-45 / ST multi-mode – up to 2 km – 1310 nm
Basic Specifications
- Manufacturer’s Part Number
- AT-MC101XL-60
- EAN
- 0767035191737
- Device Type
- Fibre media converter – RJ-45 / ST multi-mode
- Optical Wave Length
- 1310 nm
- Form Factor
- External
- Dimensions (WxDxH)
- 10.5 cm x 9.5 cm x 2.5 cm
- Power
- AC 120/230 V
- Max Transfer Distance
- 2 km
- Weight
- 294 g
- Data Transfer Rate
- 100 Mbps
- Cabling Type
- 100Base-FX, 100Base-TX
- Product Description
- Allied Telesis AT MC101XL – fibre media converter – 10Mb LAN
- Model
- Allied Telesis AT MC101XL
- Data Link Protocol
- 10Mb LAN
Networking
- Connectivity Technology
- Wired
- Cabling Type
- 100Base-FX, 100Base-TX
- Data Link Protocol
- 10Mb LAN
- Data Transfer Rate
- 100 Mbps
- Optical Wave Length
- 1310 nm
- Max Transfer Distance
- 2 km
- Status Indicators
- Port duplex mode, power, link OK, link/activity, MissingLink
- Features
- Auto-negotiation, MissingLink, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, fanless
- Compliant Standards
- IEEE 802.3u, IEEE 802.1Q
Expansion / Connectivity
- Interfaces
- 1 x Ethernet 100Base-TX – RJ-45 female ¦ 1 x Ethernet 100Base-FX – ST multi-mode female x 2
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 6 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 – 95% (non-condensing)
General
- Device Type
- Fibre media converter
- Form Factor
- External
Dimensions & Weight
- Width
- 10.5 cm
- Depth
- 9.5 cm
- Height
- 2.5 cm
- Weight
- 294 g
Miscellaneous
- Rack Mounting Kit
- Optional
- Compliant Standards
- FCC Class B certified, CSA, UL, TUV, cUL, RoHS
