UVC-G4-DOORBELL
UniFi Protect G4 Doorbell is a Wi-Fi video doorbell with a built-in display and real-time two-way audio communication.
The camera features a high-quality 5MP sensor with enhanced night vision. Image streams can be viewed in up to 1600x1200 (2MP) HD at 30 FPS. UniFi Protect G4 Doorbell includes a PIR sensor for instant motion detection alerts. Integration with UniFi Protect provides an easy-to-use interface.
Features:
- 1600×1200 (2MP) HD stream with night vision
- Integrated entrance lighting
- Real-time two-way audio with echo cancellation
- Built-in display
- Dual-band 802.11ac Wi-Fi
- PIR motion detection sensor
- Weather-resistant
- UniFi Protect integration
- View Compatible Chimes
| Mechanical Specifications | |
|---|---|
| Dimensions | 118.3 x 46.8 x 25.8 mm (4.7 x 1.8 x 1″) |
| Weight | Without mount: 130 g (4.59 oz) With flat wall mount: 178 g (6.28 oz) With 20° wedge mount: 200 g (7.05 oz) |
| Enclosure material | Polycarbonate |
| Mount materials | Flat wall mount: aluminum alloy 20° wedge mount: polycarbonate |
| Weatherproofing | IPX4 |
| Software | |
|---|---|
| Web application | UniFi Protect |
| Mobile app | UniFi Protect iOS™ and Android™ |
| Compatible Mechanical Chimes | |
|
Manufacturer Broan-NuTone Broan-NuTone Heath Zenith Craftmade Broan-NuTone Newhouse Hardware |
Model LA126WH LA11WH SL-2735 CTPW-RG LA39WH CHM3D |
| Compatible Digital Chimes | |
|
Manufacturer Broan-NuTone IQ AMERICA IQ AMERICA |
Model LA600WH DW-2850 DW-2840 |
| Transformer Specifications (EU Version) | |
| Input rating (5, 6) | 230V, 50/60Hz |
| Output rating (1, 4) | 16V AC, 15VA |
| Operating temperature | -5 to 35 º C (23 to 95º F) |
Note: UniFi Protect is required to run this product with full functionality, we recommend using it with Dream Machine Pro or Network Video Recorder
Mfr. Part #: UVC-G4-DOORBELL
